TLCP 双向身份鉴别 — ECDHE_SM4_CBC_SM3

密码套件: ECDHE_SM4_CBC_SM3 传输协议: TLCP (TCP) 参考标准: GB/T 38636-2020 | GM/T 0009-2023 | GB/T 32918-2016

重要提示：ECDHE_SM4_CBC_SM3密码套件的TLCP协议仅支持双向身份鉴别！

协议分析详情

身份鉴别类型: 双向身份鉴别（显式）

0. 协议概览

• • 协议: TLCP
• • 签名算法: SM2
• • 密码套件: 0xe011 (ECDHE_SM4_CBC_SM3)
• • CertificateRequest: YES
• • CertificateVerify: YES

一、客户端验证服务端 (双向鉴别)

客户端随机数 (ClientHello)

• • tls.handshake.type == 1
• • Random: 92fe8085d6152f553eba5a8fa1ee22e77210a85f284986675cacdabc11b7cdff
• • GMT Unix Time: 2048-02-24 10:23:01 UTC
• • Random Bytes: d6152f553eba5a8fa1ee22e77210a85f284986675cacdabc11b7cdff

服务端随机数 (ServerHello)

• • tls.handshake.type == 2
• • Random: 0c94be5cbbab0eb6bff4f0cd084a7f679af68e0a837b5aee1b2a926ec7521b32
• • GMT Unix Time: 1976-09-08 23:50:52 UTC
• • Random Bytes: bbab0eb6bff4f0cd084a7f679af68e0a837b5aee1b2a926ec7521b32

规范引用

GB/T 38636-2020 第5页: 服务端密钥为非对称密码算法的密钥对。

加密证书长度 (Server Certificate)

• • tls.handshake.type == 11
• • Certificate Length: 532
• • 十六进制(3字节): 000214

签名证书 (Server Certificate)

• • 证书数据 (DER编码完整数据):

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

签名公钥

• • 规范引用: GM/T 0009-2023 SM2PublicKey = BITSTRING { 04‖X‖Y }
• • 签名公钥: 04ca9fdb5aba25ed11906907d268c81140681204d57c3eee8ce8997b8d82cd957310dcd6dcdeb537e9feed7a2acacb6db29959615a74d0382ef700ffae319a77ae
• • X: 0xca9fdb5aba25ed11906907d268c81140681204d57c3eee8ce8997b8d82cd9573
• • Y: 0x10dcd6dcdeb537e9feed7a2acacb6db29959615a74d0382ef700ffae319a77ae

加密证书 (Server Certificate)

• • 证书数据 (DER编码完整数据):

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

加密公钥 (SM2 非压缩格式)

• • 加密公钥: 049bd6d635bbe97bcc0bbda3cb985f6146a5b15232da1e89b482d52c4b56fb86d07fdeb474f84e04e4591b2cd378ea6a50c005309fe8cea1375977e28cf65dee86
• • X: 0x9bd6d635bbe97bcc0bbda3cb985f6146a5b15232da1e89b482d52c4b56fb86d0
• • Y: 0x7fdeb474f84e04e4591b2cd378ea6a50c005309fe8cea1375977e28cf65dee86

密码套件说明

• • 0xe011 (ECDHE_SM4_CBC_SM3): 采用 SM2 密钥协商 (ECDHE) 实现密钥交换

签名值 (ServerKeyExchange)

• • Server Key Exchange 消息 tls.handshake.type == 12

规范引用: GB/T 38636-2020 §6.4.5.4:

ECDHE: signed_params = client_random + server_random + params

ECC: signed_params = client_random + server_random + enc_cert_len + enc_cert

• • ECC-SM2-EXPORT Server Params (签名值 DER编码):

3046022100ddfe2e6b8d4af7f1a519dfc474da91e92080ed3c3dd695187882ef705c53a52a022100fc38b69bda60a193190e5517640e3e1e71c9f70b56e60e8e40aa57fceb2d5571

• • R: 0xddfe2e6b8d4af7f1a519dfc474da91e92080ed3c3dd695187882ef705c53a52a
• • S: 0xfc38b69bda60a193190e5517640e3e1e71c9f70b56e60e8e40aa57fceb2d5571

User ID

• • 规范引用: GM/T 0009-2023
• • 十六进制: 31323334353637383132333435363738
• • 字符串: "1234567812345678"

签名源数据

• • ECDHE模式: client_random + server_random + key_exchange_params(69B)
• • 总长度: 133 字节
• • 完整数据:

92fe8085d6152f553eba5a8fa1ee22e77210a85f284986675cacdabc11b7cdff0c94be5cbbab0eb6bff4f0cd084a7f679af68e0a837b5aee1b2a926ec7521b3203002941042df587c2177cdc19a157e9feb37fa57f4b6ced10a48852f7beff4637928afe892f3c0217016fb85c77f2ff741cb93abdc2e1376d11e08d9f867fc62a0ad60d08

• • SM3(M): A298624E948F49B030F147ECEAF582320899463EB54BDE52C6D71FEEC8035B77

验签结果

• • 客户端验证服务端 (ServerKeyExchange签名): OK

二、服务端验证客户端

Certificate Request

• • tls.handshake.type == 13
• • Certificate type: ECDSA/SM2 Sign
• • 规范引用: GB/T 38636-2020 第5页

签名证书 (Client Certificate)

• • 证书数据 (DER编码完整数据):

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

签名公钥

• • 规范引用: GM/T 0009-2023 SM2PublicKey = BITSTRING { 04‖X‖Y }
• • 签名公钥: 04ca9fdb5aba25ed11906907d268c81140681204d57c3eee8ce8997b8d82cd957310dcd6dcdeb537e9feed7a2acacb6db29959615a74d0382ef700ffae319a77ae
• • X: 0xca9fdb5aba25ed11906907d268c81140681204d57c3eee8ce8997b8d82cd9573
• • Y: 0x10dcd6dcdeb537e9feed7a2acacb6db29959615a74d0382ef700ffae319a77ae

加密证书 (Client Certificate)

• • 证书数据 (DER编码完整数据):

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

加密公钥 (SM2 非压缩格式)

• • 加密公钥: 049bd6d635bbe97bcc0bbda3cb985f6146a5b15232da1e89b482d52c4b56fb86d07fdeb474f84e04e4591b2cd378ea6a50c005309fe8cea1375977e28cf65dee86
• • X: 0x9bd6d635bbe97bcc0bbda3cb985f6146a5b15232da1e89b482d52c4b56fb86d0
• • Y: 0x7fdeb474f84e04e4591b2cd378ea6a50c005309fe8cea1375977e28cf65dee86

签名值 (CertificateVerify)

• • 签名值 (DER编码):

304402205a9edf2474ac63e06b24c03c12de03d9924449837a67b18324f913c53204c2020220671edfe131939341f4c70bf6b5e14ccd40dcb90b89fb2ecb60fd146418746ee6

• • R: 0x5a9edf2474ac63e06b24c03c12de03d9924449837a67b18324f913c53204c202
• • S: 0x671edfe131939341f4c70bf6b5e14ccd40dcb90b89fb2ecb60fd146418746ee6

User ID

• • 十六进制: 31323334353637383132333435363738
• • 字符串: "1234567812345678"

握手消息

• • 规范引用: GB/T 38636-2020 §6.4.5.9

1. 1. ClientHello (type=1) len=67
2. 2. ServerHello (type=2) len=91
3. 3. Certificate (type=11) len=1627
4. 4. ServerKeyExchange (type=12) len=147
5. 5. CertificateRequest (type=13) len=8
6. 6. ServerHelloDone (type=14) len=4
7. 7. Certificate (type=11) len=1627
8. 8. ClientKeyExchange (type=16) len=73

• • SM3(M): 57855F19692472CEE5E1CA0C77458CEAB2D810B57BFEFA45B5D82EAB056B00D4

验签结果

• • 服务端验证客户端 (CertificateVerify签名): OK

三、结论

| 验证项目 | 结果 | | — | — | | 客户端验证服务端 (ServerKeyExchange签名) | OK | | 服务端验证客户端 (CertificateVerify签名) | OK |

四、参考标准

• • GB/T 38636-2020: 信息安全技术 传输层密码协议
• • GB/T 32905-2016: 信息安全技术 SM3密码杂凑算法
• • GB/T 32918: 信息安全技术 SM2椭圆曲线公钥密码算法
• • GM/T 0009-2023: SM2密码算法使用规范
